Mono Class D Digital Amplifier
1 x 400 Watts RMS @ 4 Ohms
1 x 600 Watts RMS @ 2 Ohms
1 x 800 Watts RMS @ 1 Ohm
1 x 800 Watts max. @ 4 Ohms
1 x 1200 Watts max. @ 2 Ohms
1 x 1600 Watts max. @ 1 Ohm
223 x 63 x 320/346 mm
1 Ohm Stability
Low Pass Filter 30 - 250 Hz
Subsonic Filter 20 - 50 Hz
Bass EQ 0 - 18 dB
Phase Shift 0°/180°
Input Sensitivity 2-8 V / 0.2-2 V
RCA In- & Outputs
Master/Slave Link Mode
Bass Remote Controller
Manufacturer's suggested retail price.
Changes and mistakes reserved.
